T3 T4 T3T4 Universale Turbo Oil Cooled Turbocharger + 2.5" Piping Pipe Kit
- Offerta valida solo oggi.
Questi articoli potrebbero interessarti !
Confronta con articoli simili
Informazioni sul prodotto
Descrizione
Application:
Perfect for all 4 or 6 CYL, 2.0L-3.5L engines
Horse Power: Capable of Boosting Horse Power up to 420HP
Cooling Type: Oil Cooled
Turbocharger Specification
Exhaust Inlet (Turbo Manifold) Flange: T3 T4 4 bolt Flange Patterns
Exhaust Outlet () Flange: V-Band Flange
Turbine Trim: 73
Turbine Inducer Diameter: 65.5 mm
Turbine Exducer Diameter: 55.9mm
Turbine A/R: 0.63
Compressor Trim: 44
Compressor Inducer Diameter: 50.5 mm
Compressor Exducer Diameter: 76 mm
Compressor A/R: 0.5
Bearing: Journal Bearing
Warranty: 2 Years
Internal Wastegate: Yes
Piping Pipe Kit Specification
Pipe Thickness: 1.8mm
Pipe length: 18''
100% brand new Never been tried or installed.
100% quality assurance tested
Made out of high quality of 6061 aluminum Manual polishing finished
Package Including:
2x 90 Degree Aluminum Pipe 2.5"
2x Straight aluminum pipe 2.5"
2x 135 Degree Aluminum Pipe×2 2.5"
2x U Aluminum Pipe×2 2.5"
6x Straight Silicon Hose 2.5" (Blue )
2x 90 Degree Silicone Hose×2 2.5"(Blue )
16x Clamps 2.5"
1x Turbo and gaskets
Notice:
* Please check the specifications carefully before bidding. If you are not sure about these information, please feel free to contact us.
* This is universal application turbo, so modification might be required for some vehicles
* Professional installation is highly recommended (No Instruction Included)
Caratteristiche
- MarcheBFO
- MaterialeAlluminio
- Referenza ManoManoME70887384
- MMID956302426972
- Rif. costruttore5EBNOI
- EAN6971362682798
