Cavo Filo Unipolare N07G9-K sez. 2,50 mmq Nero

Codice ErreBi: 18399
Vendita al metro
Prezzo per 2 metri
Note: Articolo venduto a metratura continua. 2 metri
Esempio: Se acquisti quantità 3, riceverai una metratura continua di 6 metri

Nominal voltage Uo/U: 450/750 V
Maximum operating temperature: 90°C
Minimum operating temperature: -30°C (without mechanical stress)
Minimum installation temperature: -15°C
Maximum short circuit temperature: 250°C
Maximum tensile stress: 50 N/mm2
Minimum bending radius: 4 x maximum external diameter

Use and installation
Particularly suitable in crowded environments where people’s safety is fundamental. For installation in surface or embedded conduits or similar closed systems. Suitable for fixed laying inside lighting devices and switching and control equipments. In protected installations inside command and interruption equipments, voltages are allowed up to 1000 V a.c. or 750 V d.c. to ground. The 1 mm² cross section is to be used only for lifts and elevators electric circuits or for internal connections in switchboards for signalling and control. Not suitable for outdoor installation. (ref. CEI 20-40)

Scheda Tecnica

Tipologia di prodotto: Cavo N07G9-K
Colore: Nero
Voltaggio: 750V
Temperatura operativa min.: -30°C
Temperatura operativa max.: +90°C
Materiale dell'isolante: LS0H (Low Smoke Zero Halogen)
Conduttore (Materiale): Rame Rosso
Sezione del cavo mmq: 2.50 mmq
Numero di trefoli: 16
Test Voltaggio: 1000V
Tipologia impiego: Cablaggi Interni
